Linear volume filling machine (1L)
This model adopts linear filling, machine-electrical integrated control, superior performance, and its shape conforms to the international mechanical design concept. In order to ensure the measurement accuracy, it is specially developed for small size products below 1L, the filling range is 200ml-1000ml, the filling container can be plastic bottles, glass bottles, etc., the filling speed is 900-1300 bottles/hour, mainly used for vegetable oils such as walnuts Quantitative filling of high-grade oils such as oil, olive oil, camellia oil and some small-sized oils
Linear Volume Filling Machine (5L)
This model adopts linear filling, machine-electrical integrated control, superior performance, and its shape conforms to the international mechanical design concept. The filling range is 1L-5L, and the filling container can be plastic bottles, glass bottles, iron drums, etc., and the filling speed is 1600-2600 bottles/hour. It is mainly used for quantitative filling of liquids such as vegetable oils, lubricants, and industrial products. .
Linear volume filling machine (10L-20L)
This model adopts linear filling, machine-electrical integrated control, superior performance, and its shape conforms to the international mechanical design concept. The filling range is 10L-20L, and the filling container can be plastic bottles, glass bottles, iron drums, etc., and the filling speed is 450-1100 bottles/hour. It is mainly used in vegetable oil, lubricants, chemical liquids, daily chemical industries, etc. Quantitative packaging and filling.

Configuration and performance, features:
1. Using German original SIEMENS (Siemens) PLC control to ensure stable system performance.
2. Imported electric and pneumatic control components are selected, with stable performance.
3. The photoelectric detection system adopts German products with reliable quality.
4. Leading anti-drip device to ensure no dripping during the production process.
5. Step-by-step feeding, the main section of conveying adopts frequency conversion control for higher efficiency, and the subsequent sequence (pressing, coding, light inspection, sealing, etc.) adopts unique double misalignment to make the entire line work more accurately and smoothly .
6. High and low double-speed filling, to avoid overflow phenomenon, while greatly improving production efficiency.
7. Single machine adapts to multiple varieties, and adjustment is quick and convenient.
8. The humanized control system has an intelligent protection function. It will alarm and display the cause of the failure when it encounters a failure to ensure the safety of the production process.
9. The electric capacity adjustment system has real-time data tracking function, so that the replacement of the product can be realized only from the touch screen setting, which is accurate, convenient and fast.
10. According to user needs, it can be equipped with automatic capping and capping machine, automatic continuous capping machine, dual-purpose capping machine, leak detector, aluminum foil sealing machine, inkjet printer, automatic box unpacking machine, box packing machine, folding machine Covering and sealing machines, etc. form an assembly line operation.
